2026 TOP HAT 83" X 24' EQUIPMENT HAULER WITH JUMBO RAMPS AND SPARE, 17.5K#GVWR 11764#PLC
$10,200
Trailer Specs
Stock Number:
64517
VIN/Serial Number:
4R7BU2428TN264517
Condition:
New
Year:
2026
Model:
EB16-24X83-17.5E-H
Weight (lbs):
4,236 lbs
Length:
24'
Width:
83"
GVWR (lbs):
17,500
Features:
Mini Jumbo Ramps, Spare Tire, Tandem Axle, Toolbox, Up-Rated, Wood Floor
Standard Equipment
- ST 215/75R/17.5 LRH Tires on 8-Hole
- 8000# Dexter Oil Bath 1/2 Cambered Axles w/5/8" Lug Studs
- 2 5/16" DEMCO Easy Latch Adjustable 5/Position Coupler
- 10000# Drop Leg Jack
- HD Diamond Plate Fender (Double Broke)
- Treated Pine Floor
- Break Away Unit w/Charger
- Suspension: Slipper Spring
- DOT Reflective Tape
- Sealed Flush Mount LED Lights w/Wiring Harness
- 5/8" D-Rings (6)
- Color: Stock
Options
- Spare ST215/75R/17.5 LRH on 8-Hole Black Mod
- Extra Weld-on D-Rings 5/8" (Each)
- HD 3/16" Drive Over Fenders
- Fork Rack (2-6" Channel tubes set at 46" Outside. Driver side)
- Fork Rack Tubing & dimensions can be custom w/additional fee.
- *5' Rear Slide Channel Ramps (Must Purchase 2 Rear Stabalizer Jacks)
- Rear Stabalizer Jack (5K Top Wind Pipe Mount)
- 5' Fold-up Channel Ramp w/Adjustable Knees & Spring Assist
- **3' Self Cleaning Cleated Dovetail & 3' Mini Jumbo Spring Assist Ramps (Must be 20' or longer)
- 5' XM Fold Up Channel Ramp w/Adjustable Knees & Spring Assist
- Above Ramp is 24" Wide Covered w/Expanded Metal
- 3-4' Dovetail ILO 2' Dovetail
- 2' Self Cleaning Cleated Dovetail ILO 2' Treadplate Dovetail
- *Rear Slide-N Ramps on 16' will be 4 1/2'.
- **Jumbo Ramps NA on lengths less than 20'
Frame Structure
- Frame: 8"x13# I-Beam
- Tongue: Integrated w/Frame
- Front Bumper w/Side Gussets
- Crossmembers: 3" Channel 16" OC
- Stake Pockets w/3/8x2 Rubrail
- 2' Treadplate Dovetail
- Flush Floor
- Oversized Toolbx/Spare Holder in Tongue
- Diamond Plate Fender Step/Braces
