2027 Big Tex Trailers 35SA-14R1A-4PBK
Trailer Specs
Meet the 2027 Big Tex Trailers 35SA Single Axle Utility (77" x 14')-a tube-top utility trailer that's equal parts workhorse and weekend wingman, finished in a look that stands out whether it's parked in the driveway or backed up to the jobsite.
Built around a steel frame and an open utility configuration, this trailer keeps things simple in the best way: a big, usable deck and the strength to take on the kind of loads that make lesser rigs sweat. With a cargo area measuring 169.5" long by 77" wide, you've got a generous platform for everything from yard equipment to building supplies. The plank flooring gives your cargo a solid, dependable base, while the front and side rails add a little extra confidence when you're hauling awkward shapes that like to shift.
Loading day feels less like a chore thanks to the rear integrated ramp (one ramp, right where you want it). Roll on, roll off, and get back to what you're actually trying to do. Up front, a manual leveling jack helps you keep hookups and unhooks straightforward-especially when the ground isn't perfectly cooperative.
Underneath, the 35SA keeps its footing with steel wheels and ST205/75R15 Load Range C radial tires, paired with a single axle using a multi-leaf spring setup. The axle is rated at 3,500 lbs, and when it's time to rein things in, electric drum brakes provide controlled stopping power. Hookup is classic and confident with a 2" A-frame coupler.
Numbers matter when you're hauling, and this one brings the right kind: GVWR of 2,995 lbs, a payload capacity of 1,922 lbs, and a dry weight of 1,073 lbs. It sits at a practical 18" platform height, keeping loading manageable without sacrificing utility.
In short, this Big Tex 35SA is the kind of trailer that turns "Can we move that?" into "Yep-let's go."
- Black: +$0
- Jet Blue: TBA
- Desert Tan: TBA
- Implement Green: TBA
- Slime Green: TBA
- Equipment Orange: TBA
- Red: TBA
- Grey: TBA
- White: TBA
- Medium Yellow: TBA
- Structure Warranty (Months): 36
- Dimensions: Standard
- Length: 205.63 in; 5223 mm
- Width: 77 in; 1955.8 mm
- Floor/Deck Length: 169.5 in; 4305.3 mm
- Platform Height: 18 in; 457.2 mm
- Weight: Standard
- Dry Weight: 1073 lbs; 486.7 kg
- Payload Capacity: 1922 lbs; 871.8 kgs
- GVWR: 2995 lbs; 1358.5 kgs
- Construction: Standard
- Frame: Steel
- Trailer Configuration: Open
- Leveling Jacks: Standard
- Leveling Jack Type: Front Manual
- Ramp: Standard
- Number Of Ramps: 1
- Ramp Type: Integrated
- Ramp Location: Rear
- Side Rail / Wall: Standard
- Side Rail / Wall Location: Front / Sides
- Cargo Area Dimensions: Standard
- Cargo Area Length: 169.5 in; 4305.3 mm
- Cargo Area Width: 77 in; 1955.8 mm
- Cargo Area Height: 17 in; 431.8 mm
- Cargo Area Flooring Type: Plank
- Width Between Fenders: 77 in; 1955.8 mm
- Tilt Bed: No
- Wheels: Standard
- Wheels Composition: Steel
- Number Of Axles: 1
- Axle Type: Multi-Leaf Spring
- Axle Capacity: 3500 lbs; 1587.6 kg
- Tires: Standard
- Rear Tire (Full Spec): ST205/75R15 Load Range C Radial Tires
- Brakes: Standard
- Rear Brake Type: Electric Drum
- Trailer Coupler: Standard
- Coupler Type: A-Frame
- Coupler Size (in): 2
- Paint: Standard
