The Tube Top ATV Utility Trailer is a versatile and practical solution designed for transporting ATVs and other recreational vehicles. Featuring innovative side loading ramps, this trailer allows for easy loading and unloading from both sides, making it convenient to maneuver in tight spaces and efficiently load multiple vehicles.

In addition to the side ramps, the trailer is equipped with a rear spring assist ramp gate. This feature reduces strain on your back, making it simple load vehicles with minimal effort. Together, the side loading ramps and spring assist rear gate facilitate quick and efficient loading of multiple ATVs, perfect for group outings or events.

GVWR (lbs)

7000

GAWR (lbs/axle)

3500

Curb Weight

1910

Payload

5090

Width

7

Length

16

Overall Length

239

Deck Height

18

Coupler Height

16

Length Deck

192

Length Ramp

48

Height Deck

18

Width Between Fender

81.5

Type

OPEN

Axle

(2) 3500 lb. Spring Brake

Breakaway

Battery, Switch, and Lanyard

Connector Plug

Round 7-pin Blade

Coupler

2-5/16" A-Frame

Crossmembers

3" x 2" x 3/16" Steel Angle

Decking

2" Pressure Treated Pine, Board Retainers

Exterior Finish

Industrial Grade Polymer Finish

Exterior Lights

Full LED, DOT Compliant

Exterior Storage

Ready for Drop-In (Recessed) Lockable Toolbox, Spare Tire Carrier

Fenders

Double Break Tread Plate

Frame

3" x 2" x 1/4" Steel Angle

Hubs

Easy Lube

Ramp(s)

4' Fold Flat HD Reinforced Spring Assist with Grab Handle (Ladder Style), Self-Retained Gate Pins

Safety Chains

DOT Compliant

Sides

13" Tall, 5' Fabricated Steel Ramps (Side Storing)

Tires

ST205/75R15C 6-PLY

Tongue

4" Steel Channel

Tongue Jack

2K Set-Back

Top Rail

2" x 2" Steel Tube

Uprights

2" x 2" Steel Tube

Wheels

15", 5-Lug Steel
