2027 Big Tex Trailers 16TI-24A-BK 16'+8' Stationary 17,500# GVWR
Trailer Specs
The Big Tex 16TI I-Beam Tilt Trailer is the industry standard for operators who need a grit-tested, ramp-free solution for hauling low-clearance gear. Built on a massive 8-inch I-beam frame forged for heavy hauls, this tilt trailer features a hydraulic deck with a 12-degree angle and a diamond plate knife edge to let scissor lifts and skid steers glide on without a fight. The EZ Pedal locking mechanism keeps the tilt deck rock-solid for the long haul, while integrated fork pockets and a mega-sized lockable toolbox keep your deck clear and your gear secure. When the job is demanding and the equipment is heavy, the 16TI is the undisputed workhorse your fleet can count on.
| Standard Feature | ||
|---|---|---|
| Axles | 2 - 8,000# Premium, 4" Drop-Axles with Quick-Lubricating Hubs | Available Options |
| Brakes | Forward Self-Adjusting Electric Brakes on Both Axles | |
| Suspension | Multi-Leaf Spring w/ Equalizer | |
| Tongue | 8" I-beam Tongue | |
| Coupler | Adjustable 2-5/16" Demco EZ Latch | Adjustable Pintle in Channel in Lieu of Coupler |
| Safety Chains | 3/8" Grade 70 w/ Safety Latch Hook (2 ea) | |
| Jack | 12,000# Drop-Leg Jack (Side Wind) | |
| Frame | 8" I-Beam | |
| Cross-Members | 3" Channel on 16" Centers | |
| Front Stop Rail | Fabricated Front Stop Rail | |
| Floor | Treated Pine Floor | |
| Fenders | 9" x 72" 14 Ga. Diamond Plate Double Square Broke w/Back (Removable) | |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) | |
| Trailer Plug | 7-Way RV | |
| Lights | Recessed, Grommet-Mounted L.E.D. Lighting | |
| Wiring | Sealed, Modular Cold-Weather Wiring Harness | |
| Tires | ST215/75 R-17.5 Load Range H | |
| Bolt Pattern | 8-Bolt | |
| Wheels | Black Mod | |
| Spare Mount | Spare Tire Mount in Toolbox | |
| Spare Tire | Not Included | Spare Tire (ST215/75 R-17.5 LR-H) |
| Paint Color | Black | |
| Tilt Deck Operation | Hydraulic Dampening with Valve Control and Single Side, EZ Pedal Locking Mechanism | |
| Rubrail | Rub Rail Along Both Sides | |
| Tie-Downs | (6) 5/8" D-Rings | |
| Break-Away Kit | Complete Breakaway System w/ Zip?? Breakaway Cable and Charger | |
| Storage | Full Tongue Tool Box with Locking Lid | |
| Cargo Winch | ||
| Tilt Deck Angle | 12° |
